SoundID Reference for Multichannel and Apollo Monitor Correction Add-on bundle (download only)

Achieve ultra-accurate monitoring — effortlessly

Calibrating your studio monitors with SoundID Reference Multichannel is a piece of cake. Just connect a measurement microphone to your audio interface, fire up the software, and you're good to go (microphone sold separately). It comes with more than 400 ready-to-use headphone calibration profiles, so tailoring the software to your headphones is even easier. SoundID Reference Multichannel's calibration profiles creates a target frequency response that's flat across all audible frequencies. This calibration software also allows you to make custom, real-time adjustments to the target curve for profiles that are tailored to your individual application. And since you can save as many profiles as you'd like, switching between different speakers, headphones, and rooms is 100% seamless.

Overflowing with pro-level features

Sonarworks SoundID Reference Multichannel is packed with an astounding number of pro-requested features. For starters, the software includes both a multichannel DAW plug-in and a stereo standalone desktop application. You get three filter modes: zero latency, mixed, and linear phase, along with extra DSP processing controls, including mono, dry/wet, and safe headroom. The SoundID Reference application includes MIDI mapping for various parameters, as well as user presets for switching between predefined output devices/channel pair combinations. Phase alignment of channels for accurate time delay calibration and calibration profile export for supported hardware, including Avid's MTRX with DPQ DSP and MTRX Studio, DAD's AX32 with SPQ DSP, the Dolby Atmos Renderer Mastering Suite, and Jones-Scanlon studio monitors is also included.

Key features of SoundID Reference

→ Reliable, consistent, easy to use calibration software for all of your audio

system:

○ Ready-to-use headphone calibration for 500 models

○ Accurate speaker measurements and calibration for audio systems from

stereo up to 9.1.6 channels

○ 3 filter modes: Zero Latency, Mixed and Linear Phase

○ Additional DSP processing controls: Mono, Dry/Wet and Safe Headroom

○ MIDI mapping in the SoundID Reference app for various controls

○ User Presets in the SoundID Reference app for switching quickly

between predefined output device/channel pair combinations

→ Control your target sound:

○ Flat target curve used by over 200'000 music creators globally

○ Custom Target: target curve adjustments in real time

○ Translation Check: simulate 20 different devices and environtments

→ High performance and flexibility:

○ Zero latency plugin DSP

○ Near-zero latency system-wide calibration on Windows

○ Native support for Apple Silicon M-series chip devices)

→ Export your calibration profile to supported hardware:

○ Apply calibration directly on DSP-enabled hardware

○ 10 device integrations available (audio interfaces, speakers, Dolby

Atmos Renderer, and more)

○ See the exact list of calibration profile types and supported targets

devices here: SoundID Reference Integrations

Key features of Apollo Monitor Correction Add-on

→ Speaker and headphone calibration running directly on Apollo X hardware.

→ Hardware calibration for over 500 supported headphone models.

→ Multiple outputs calibrated simultaneously: one speaker profile, and up to two

headphone profiles (depending on the Apollo X model used)

→ Calibrated bass management for stereo speaker setups with subwoofer

→ Supported target modes include: Flat, Dolby Atmos Music curve, user Custom

Target, and various device emulation targets via Translation Check.

→ Near-zero latency integrated performance.

What's included

→ Activation key for the SoundID Reference product license: the product can be

activated and used on  3 devices

→ Activation key for the Apollo Monitor Correction Add-on product license: the

product can be activated and used on 3 devices

→ SoundID Reference standalone app for speakers and headphones ASIO,

WASAPI, APO, HAL

→ SoundID Reference DAW plugin for speakers and headphones AU, VST2, VST3,

AAX

→ Averaged profiles for 500 supported headphone models

→ Apollo Monitor Correction Add-on for integrated functionality with Apollo X

devices

System requirements

→ A supported Apollo X audio interface:

○ Apollo X Gen 1: Apollo Twin X Duo/Quad, Apollo Twin X USB, Apollo x4,

Apollo x6, Apollo x8, Apollo x8p, Apollo x16

○ Apollo X Gen 2: Apollo Twin X Duo/Quad, Apollo x4, Apollo x6, Apollo x8,

Apollo x8p, Apollo x16, Apollo x16D

→ A supported operating system

○ macOS 11 Big Sur, 12 Monterey, 13 Ventura, 14 Sonoma, 15 Sequoia

○ Windows 10, 11

→ UAD Console app v1.2.1 (or newer) installed, and UAD2 Software v11.5.1 (or

newer) installed

→ 2.0 - 9.1.6 speaker system

→ Sonarworks supported or Sonarworks individually calibrated headphones

→ Internet connection for periodic license validation (full offline use not

supported)

→ SoundID Reference Measurement Microphone, or Sonarworks XREF 20

Measurement Microphone

→ Microphone stand and clip (ø21 mm/0.83ˮ) for multichannel system

measurments

→ XLR to XLR audio cable

→ Audio interface requirements during the speaker measurement process:

○ 48v Phantom Power support

○ The same audio interface must be used for input/output

○ The audio interface must support and be set to one of the following

sample rate formats: 44.1kHz, 48kHz, 88kHz, 96kHz, 192kHz

○ The audio hardware setup must consist of a single external hardware

device only (additional preamp units are supported)

Sound Id Integrations
