Proel Playmix 6

Name: Proel Playmix 6
Brand: Proel
Price: ₹13,545
Availability: InStock

Product Code:
Availability:

Proel Playmix 6
In Stock

₹13,545

Call +91 98843 04425 for availability

Description Specifications Reviews (0)

MONO INPUT CHANNEL
Mic Input	sensitivity	from -10 to -50 dB	Balanced XLR-F
	impedance	2 Kohm
Line Input	sensitivity	from +20 to -20 dB	Balanced JACK
	impedance	10 Kohm
Lo cut		75Hz, 18dB/oct.
EQ	HIGH (shelving)	±15 dB @ 12KHz
	MID (peaking)	±15 dB @ 2.5KHz
	LOW (shelving)	±15 dB @ 80Hz
Compressor	Fet	CH 1-2, 1-knob
STEREO INPUT CHANNEL
Mic Input	sensitivity	from -10 to -50 dB	Balanced XLR-F
	impedance	2 Kohm
Line Input	sensitivity	from +20 to -20 dB	Balanced JACK
	impedance	10 Kohm
Line Input	sensitivity	-10 dB	Balanced JACK, RCA
	impedance	10 Kohm
EQ	HIGH (shelving)	±15 dB @ 12KHz
	MID (peaking)	±15 dB @ 2.5KHz
	LOW (shelving)	±15 dB @ 80Hz
MASTER SECTION
MAIN MIX	nom. out level	+4 dBu	Balanced JACK and XLR-M
C. ROOM output	nom. out level	0 dBu	Unbalanced JACK
FX/AUX output	nom. out level	0 dBu	Unbalanced JACK
HEADPHONES	min. impedance	32 ohm
	max. out level	(2x) 193 mW	Stereo JACK
DIGITAL EFFECT PROCESSOR
Effects		100 presets
A/D and D/A converters		24 bit
DSP resolution		24 bit
Controls		2-DIGIT display, DIAL, PEAK LED, MUTE switch, MUTE footswitch
GENERAL SPECIFICATIONS
Maximum level	all outputs	+22 dBu
Crosstalk	meas. at 1 KHz	> 82 dBu
HUM & Noise	unweighted	< -93 dBu
THD + Noise	at +4dB, 1kHz	< 0,008 %
Dimensions (WxHxD)		275 x 279 x 81 mm
Weight		2,50 kg
POWER REQUIREMENTS
Supply		18 VAC 1000 mA - use only supplied AC/AC ADAPTER
Mains Supply Voltage		110-120 VAC (±10%) 50 / 60 Hz (US plug)
		230-240 VAC (±10%) 50 / 60 Hz (EU plug)
		240 VAC (±10%) 50 / 60 Hz (UK plug)

Consumption		34 W

PLAYMIX6

Compact 6-channel mixer with DSP and USB/BT interface

PLAYMIX is a series of mixers created by PROEL to offer in a very compact and stylish package a high inputs density, a full set of features and a superior audio quality, at a very convenient price point.

PLAYMIX mixers are available in 3 models, with the same channel and master functions, but offering 6, 8 or 10 inputs respectively. The mono MIC/LINE channels feature low-noise, high-headroom microphone preamps, 3-band EQ with sweep MIDs and HPF, and 60mm control faders, for a full control of your sound.

All models feature an advanced DIGITAL section with LCD display, including:

– A high-quality 24-bit built-in DSP with 100 studio-grade presets of single and combined effect (REVERBS, DELAYS, MODULATIONS)

– A 48KHz stereo USB audio interface for playing/recording thru PC connection

– A built-in MP3 player from USB memory key or BLUETOOTH interface

– On-the-go stereo recording on USB memory key

Carefully designed and engineered in Italy by PROEL, PLAYMIX mixers are hosted in rugged cases, providing extended durability for a stage-proof use and they offer in an ultra-compact format the performance of professional consoles, delivering a clean and accurate sound for a wide range of applications.
