SoundID Reference - Upgrade from Reference 3 or 4 Studio Edition to SoundID Reference for Multichannel (key only)

SoundID Reference for Multichannel delivers accurate and reliable reference sound for speaker setups from simple stereo up to 9.1.6 Atmos systems. This upgrade allows you to keep all existing room & headphone profiles owned in Reference 4. The version for multichannel provides all the features in SoundID Reference for Speakers & Headphones (stereo version), allows you to calibrate your multichannel studio speakers to set the frequency response target to be completely flat, and to choose from various target curve options. A simple and guided software setup minimizes human error to the minimum to allow more room for creativity and less for technical details.

IMPORTANT! This upgrade product is not compatible with educational licenses.

Key features

→ Reliable, consistent, easy-to-use calibration software for all of your audio systems:

○ Accurate speaker measurements and calibration for audio systems from

stereo up to 9.1.6 channels

○ High-accuracy SoundID Reference Measurement Microphone with

individual multi-angle calibration curves

○ Ready-to-use headphone calibration for 500 models

→ Control your target sound:

○ Flat target curve used by over 250'000 music creators globally

○ Customize your target by limiting the calibration frequency range or

adjusting the target curve manually

→ High performance and flexibility:

○ Zero-latency plugin DSP for Multichannel

○ Phase alignment of channels for high-accuracy time-delay calibration

○ Native support for Apple Silicon M-series chip devices)

→ Export your calibration profile to supported hardware:

○ Apply calibration directly on DSP-enabled hardware

○ 10 device integrations available (audio interfaces, speakers, Dolby

Atmos Renderer, and more)

○ See the exact list of calibration profile types and supported targets

devices here: SoundID Reference Integrations

○ ADAM Audio A Series (stereo/multichannel speaker profile export)

○ Fluid Audio Image series (stereo/multichannel speaker profile export)

What's included

→ An upgrade code for your existing product license: after upgrading, the product

can be activated and used on 3 devices

→ A new 90° microphone calibration profile compatible with multichannel

measurements for the existing SoundID Reference Measurement Microphone

and Sonarworks XREF 20 measurement microphone owners 0°; 30°; 90°, also

downloadable in TXT format for third-party use)

→ SoundID Reference DAW plugin for Multichannel AAX, AU, VST2, VST3

→ SoundID Reference standalone app for Stereo ASIO, WASAPI, APO, HAL



System requirements

→ A valid permanent Reference 4 Studio Edition license

→ macOS 11 Big Sur, 12 Monterey, 13 Ventura, 14 Sonoma, 15 Sequoia

→ Windows 10, 11

→ Internet connection for periodic license validation (full offline use not

supported)

→ SoundID Reference Measurement Microphone, or Sonarworks XREF 20

Measurement Microphone

→ Microphone stand for multichannel system measurements

→ A microphone clip for the measurement microphone that is being used. For

Sonarworks measurement microphones, a ø21 mm 0.83ˮ clip is needed

→ Audio interface requirements during the speaker measurement process:

○ 48v Phantom Power support

○ The same audio interface must be used for input and output

○ The audio interface must support and be set to one of the following

sample rate formats: 44.1kHz, 48kHz, 88kHz, 96kHz, 192kHz

○ The audio hardware setup must consist of a single external hardware device

device only (additional preamp units are supported)
